Jinko Solar 475W Tiger Neo III Dual Glass Panel
$295.00
- Description
- Specifications
- Datasheet
Description
Jinko Solar 475W Tiger Neo III Dual Glass Panel
The Jinko Tiger Neo III 475W solar panel delivers high efficiency and long term performance using advanced N-type TOPCon cell technology. This design increases front side power output while improving temperature behaviour. As a result, the panel maintains stable energy production across a wide range of operating conditions.
In addition, the panel performs strongly in low light environments. Its enhanced cell structure captures more available sunlight during cloudy conditions and early or late daylight hours. Because of this, the Tiger Neo III supports more consistent daily energy yield compared to conventional designs.
The all black appearance combines with a dual glass construction to deliver both visual appeal and structural strength. Advanced metallisation and refined encapsulation improve resistance to PID, LID, LeTID, and UV degradation. Consequently, the panel maintains stable output over its service life.
Jinko designed this module for demanding installation environments. The reinforced frame and heat strengthened glass withstand front side loads of up to 6000Pa and rear side loads of up to 4000Pa. An IP68 rated junction box further protects the system from dust and moisture, making the panel suitable for rooftop and ground mounted arrays.
At STC, the 475W model achieves a module efficiency of approximately 23.77 percent. First year degradation is limited to 1 percent, followed by an annual degradation rate of just 0.35 percent. Jinko supports this performance with a 25 year product warranty and a 30 year linear power warranty, which makes the Tiger Neo III a strong choice for long term solar investments.
Key Features
-
475W maximum power output
-
N-type TOPCon monocrystalline cell technology
-
All black mono facial module with dual glass construction
-
Strong low light and high temperature performance
-
Enhanced resistance to PID, LID, LeTID, and UV degradation
-
Certified mechanical load rating of 6000Pa front and 4000Pa rear
-
IP68 rated junction box
-
25 year product warranty and 30 year linear power warranty
Electrical Specifications (STC)
-
Maximum Power (Pmax): 475 W
-
Maximum Power Voltage (Vmp): 31.13 V
-
Maximum Power Current (Imp): 15.26 A
-
Open Circuit Voltage (Voc): 36.44 V
-
Short Circuit Current (Isc): 15.85 A
-
Module Efficiency: 23.77 %
-
Power Measurement Tolerance: ±3 %
-
Power Sorting: -5 W to +15 W
Temperature Coefficients
-
Temperature Coefficient of Pmax: -0.26 % / °C
-
Temperature Coefficient of Voc: -0.24 % / °C
-
Temperature Coefficient of Isc: 0.046 % / °C
Mechanical Specifications
-
Cell Type: N-type Monocrystalline (TOPCon)
-
Number of Cells: 192 (48 Ă— 4)
-
Dimensions: 1762 Ă— 1134 Ă— 30 mm
-
Weight: 21.5 kg
-
Front Glass: 1.6 mm heat strengthened glass with anti-reflection coating
-
Back Glass: 1.6 mm heat strengthened glass
-
Frame: Anodised aluminium alloy
-
Junction Box: IP68 rated
-
Protection Class: Class II
-
Fire Rating: IEC Class C
Mechanical Load Ratings
-
Front Side Static Load: 6000 Pa
-
Rear Side Static Load: 4000 Pa
System & Installation
-
Maximum System Voltage: 1500 V DC (IEC)
-
Maximum Series Fuse Rating: 30 A
-
Output Cables: ≥4.0 mm²
-
Cable Length: 600 mm (+), 400 mm (-)
-
Connector Type: Jinko PV connectors
-
MC4-EVO2: Available on request
Operating Conditions
-
Operating Temperature Range: -40 °C to +70 °C
-
Short Term Temperature Limit: Up to 85 °C
Packaging
-
Panels per Pallet: 37
-
Panels per Stack: 74
-
Panels per 40 ft HQ Container: 962
Warranty
-
Product Warranty: 25 years
-
Linear Power Warranty: 30 years
-
First Year Degradation: 1 %
-
Annual Degradation Thereafter: 0.35 %
